IDP30E65D1
  • IDP30E65D1

IDP30E65D1

Active and preferred

Rapid 1 switching 650 V, 30 A emitter controlled power silicon diodes in a TO-220 real2pin package is perfectly suited for Power Factor Correction (PFC) topologies, typically found in major home appliances such as air conditioners and washing machines.

Infineon Technologies IDP30E65D1 Product Info

16 April 2026 0

Parameters

Configuration

Single

I(FSM) max

180 A

IF max

60 A

IF

30 A

IR max

40 µA

Irrm

7 A

Mounting

THT

Operating Temperature range

-40 °C to 175 °C

Package

TO-220

Ptot max

143 W

Qrr

0.51 µC

RthJC max

1.05 K/W

trr

95 ns

VF max

1.7 V

VF

1.35 V

Voltage Class max

650 V

Apps

Home appliances, Washing and drying

Features

  • 1.35 V temperature-stable VF
  • Highest softness-factor for:
  • Ultimate softness
  • Low EMI filtering
  • Lowest Irrm for:
  • Low turn-on losses on boost switch
  • For 18 kHz to 40 kHz applications
