IDP08E65D1
  • IDP08E65D1

IDP08E65D1

Active and preferred

Rapid 1 switching 650 V, 8 A emitter controlled power silicon diodes in a TO-220 real2pin package is perfectly suited for Power Factor Correction (PFC) topologies, typically found in major home appliances such as air conditioners and washing machines.

Infineon Technologies IDP08E65D1 Product Info

16 April 2026 0

Parameters

Configuration

Single

I(FSM) max

64 A

IF max

16 A

IF

8 A

IR max

40 µA

Irrm

2.8 A

Mounting

THT

Operating Temperature range

-40 °C to 175 °C

Package

TO-220

Ptot max

56 W

Qrr

0.17 µC

RthJC max

2.69 K/W

trr

80 ns

VF max

1.35 V

VF

1.35 V

Voltage Class max

650 V

Apps

Home appliances, Uninterruptible power supplies (UPS)

Features

  • 1.35 V temperature-stable VF
  • Highest softness-factor
  • Low EMI filtering
  • Lowest Irrm
  • Low turn-on losses on boost switch
  • Switching between 18 kHz & 40 kHz
