Active and preferred
Certifications |
ISO 26262-ready |
Channels |
1 |
Classification |
ISO 26262-ready |
Control Interface |
Discrete |
Diagnostics |
- |
EAS/Avalanche Energy |
105 mJ |
EAS (Energy capability) |
105 mJ |
Family |
HITFET™ + 12V |
ID(lim) min |
20 A |
ID |
5 A |
IL(LIM) min |
20 A |
IL(nom) |
5 A |
IL (Short Circuit Current) |
20 A |
Load Current |
5 A |
Mounting |
SMT |
Nominal Load Current per channel |
5 A |
Operating Temperature range |
-40 °C to 150 °C |
Planned to be available until at least |
2039 |
Protection strategy |
Auto-restart |
RDS (on) (@ Tj = 150°C) max |
70 mΩ |
RDS (on) (@ Tj = 25°C) |
30 mΩ |
Recommended Operating Voltage max |
40 V |
toff (Turn OFF time) max |
210 µs |
ton (Turn ON time) max |
115 µs |
VDS max |
40 V |
Domain controller for ADAS & autonomous driving, Automotive body electronics & power distribution, Automotive body control module (BCM), HVAC control module
