MAX96716A

RECOMMENDED FOR NEW DESIGNS

Dual GMSL2 to CSI-2 Deserializer

Analog Devices MAX96716A Product Info

10 February 2026 6

Features

  • Full-Duplex Capability over a Single Coax or STP Cable
    • 3Gbps or 6Gbps Forward Link Rates
    • 187.5Mbps Reverse Link Rate
  • Dual Four-Lane D-PHY or Dual Two-Lane C-PHY MIPI CSI-2 v1.3 Output Ports
    • Aggregation and Replication Functions
    • 16 Virtual Channel Support
    • Supports RAW8/10/12/14/16/20, RGB565/666/888, YUV422 8-/10-Bit, User-Defined and Generic Long-Packet Data Types
  • Advanced MIPI D-PHY v1.2 Transmitters
    • 80Mbps to 2.5Gbps per Lane
  • Advanced MIPI C-PHY v1.0 Transmitters
    • 182Mbps to 4.56Gbps per Lane
  • Reference-over-Reverse (RoR) Channel Supports Crystal-Free Operation of Serializer
  • ASIL-Relevant Functional-Safety Features
    • ASIL-B Compliant
    • End-to-End Data Integrity Through CRC in Tunnel Mode
    • R-S FEC for Protection of Forward Video and Control-Channel Data
    • 16-Bit CRC Protection of Side-Channel Data (I2C, UART, SPI, GPIO) with Retransmission upon Error Detection
    • 32-Bit CRC Protection of Video Line Data
  • Forward- and Reverse-Channel PRBS for BER Testing of Serial Link
  • Continuous Link-Margin Monitoring and Optimization
    • Continuous Adaptive Equalization
    • Forward and Reverse Channel Eye-Opening Monitor for Continuous Link Margin Diagnosis
  • Concurrent Side-Channel for Device Configuration and Communication with Peripherals
    • I2C/UART, Pass-Through I2C/UART, SPI, GPIO, and Register-Programmable GPIO
    • Four Hardware-Programmable Device Addresses
  • 48-Lead 7mm x 7mm TQFN Side-Wettable Package with 0.5mm Lead Pitch

Part details & applications

The MAX96716A converts dual GMSL2 serial inputs to MIPI CSI-2. It also transmits and receives control-channel data, enabling transmission of forward-path video and bidirectional control data. The GMSL2 link operates at a fixed rate of 6Gbps or 3Gbps in the forward direction, and 187.5Mbps in the reverse direction.

The GMSL™ inputs operate independently, allowing video with different timing and resolution to be received on each input.

Video data from both inputs can be aggregated for output on a single CSI-2 port or replicated on a second port for redundant processing.

The device and connected serializer are programmed through I2C or UART.

Operation is specified over the automotive temperature range of -40°C to +105°C and the device is AEC-Q100 qualified.

Data may be transmitted over low-cost 50Ω Coax or 100Ω STP cables that meet the GMSL2 channel specification. Contact the factory for the GMSL2 channel specification.

Table 1. Typical Maximum Cable Length vs. Attenuation
  3.2mm Ø 50Ω Coax, Foam Dielectric 2.7mm Ø 50Ω Coax, Solid Dielectric 100Ω Shielded-Twisted Pair, AWG26
Attenuation at 3GHz (Typ, Room Temp) 0.9dB/m 1.6dB/m
