Analog Devices MAX38902E Product Info

• Delivers Flexible Operating Range
  • 1.7V to 5.5V Input Voltage Range
  • 0.8V to 5.0V Output Voltage Range
  • 500mA Maximum Output Current
  • 100mV Maximum Dropout at 500mA Load (3.6V_IN)
  • < 0.1µA Shutdown Supply Current
• Reduces Noise and Improved Accuracy
  • 14µV_RMS Output Noise, 10Hz to 100kHz
  • 600µA Operating Supply Current
  • 45dB PSRR at 100kHz
  • ±1% DC Accuracy Over Load, Line, and Temperature
• Enables Easy-of-Use and Robust Protection
  • Minimum C_OUT 4µF
  • Programmable Soft-Start Rate
  • Overcurrent and Overtemperature Protection
  • Output-to-Input Reversed Current Protection
  • POK Output
  • Active Discharge of 800Ω at OUT
• Reduces Size, Improves Reliability
  • 2mm x 2mm 8-pin TDFN Package
  • -40°C to 125°C Operating Temperature

The MAX38902E is low-noise linear regulator that delivers up to 500mA of output current with only 14μV_RMS of output noise from 10Hz to 100kHz. This regulator maintains ±1% output accuracy over a wide input voltage range, requiring only 100mV of input-to-output headroom at full load. The 600µA no-load supply current is independent of dropout voltage. The MAX38902E has an 800Ω active discharge feature to quickly discharge output capacitors.

The MAX38902E has a resistor adjustable output voltage in the range of 0.8V to 5.0V and includes an active-low POK output. The device features a programmable output soft-start rate, output over-current and thermal overload protection.

The MAX38902E is offered in an 8-pin TDFN package.

Applications

• Audio Systems
• Communication Circuitry
• High-Resolution Data Acquisition Systems
