MAX3471

PRODUCTION

1.6µA, RS-485/RS-422, Half Duplex, Differential Transceiver for Battery-Powered Systems

Analog Devices MAX3471 Product Info

10 February 2026 5

Features

1.6µA Supply Current with Receiver Enabled
+2.5V to +5.5V Single-Supply Operation
True Fail-Safe Receiver Input
Available in µMAX Package
1/8-Unit-Load Receiver Input
-7V to +10V Common-Mode Input Voltage Range

Part details & applications

The MAX3471 half-duplex transceiver is intended for lithium battery-powered RS-485/RS-422 applications. It draws only 1.6µA (typical) supply current from a 3.6V supply with the receiver enabled and the driver disabled. Its wide 2.5V to 5.5V supply voltage guarantees operation over the lifetime of a lithium battery.

This device features true fail-safe operation that guarantees a logic-high receiver output when the receiver inputs are open or shorted. This means that the receiver output will be a logic high if all transmitters on a terminated bus are disabled (high impedance). The MAX3471 has a 1/8-unit load input resistance. When driver outputs are enabled and pulled above VCC or below GND, internal circuitry prevents battery back-charging.

The MAX3471 is available in an 8-pin µMAX package.

Applications

Battery-Powered Differential Communications
Level Translators
Remote Meter Reading
