MAX25307

RECOMMENDED FOR NEW DESIGNS

Two/Three-Output, Low-Noise LDO Linear Regulators Industry's Only Auto-Qualified Low-Voltage Triple Output LDO Linear Regulator

Analog Devices MAX25307 Product Info

10 February 2026 5

Features

1.7V to 5.5V Input Voltage Range
Factory-Selectable Output Voltage of 0.6V to 3.7875V in 12.5mV Steps
37μV_RMS Output Noise, 10Hz to 100kHz
1.95mA (max) Operating Supply Current
70dB PSRR at 10kHz
600mA Maximum Output Current (OUT1)
300mA Maximum Output Current (OUT2/3)
±1.25% DC Accuracy over Load, Line, and Temperature

155mV (max) Dropout at I_MAX1/2/3 Load (3.3V_IN)
< 1µA Shutdown Supply Current
Overcurrent and Overtemperature Protection
Output-to-Input Reverse Current Protection
Individual RESET Outputs
3mm x 3mm, 16-Pin TQFN Package
−40°C to +125°C Grade 1 Automotive Temperature Range

Part details & applications

The MAX25307/MAX25308 are a two/three-output linear regulator family that deliver up to 600mA on channel 1 and up to 300mA on channels 2 and 3 with only 37μV_RMS of output noise from 10Hz to 100kHz. These regulators maintain ±1.25% output accuracy over a wide input voltage range, requiring only 155mV (max) of input-to-output headroom at full load. The 1.95mA maximum no-load supply current is independent of dropout voltage. Each output is factory programmable between 0.6V to 3.7875V in 12.5mV steps. No external components are needed except for the input, output, and bypass capacitors. Each output has an independent enable input and active-low RESET output.

Applications

Infotainment Systems
Point of Load
Advanced Driver-Assistance Systems (ADAS)
