MAX20071

PRODUCTION

Single 600mA/1A 2.2MHz Low-Voltage Step-Down DC-DC Converter

Analog Devices MAX20071 Product Info

10 February 2026 7

Features

Rich Feature Set in Ultra-Small Footprint
- High Efficiency DC-DC Converter
- Up to 1A Output Current.
- 3.0V to 5.5V Operating Supply Voltage
- Resistor Adjustable or Factory-Preset Output Voltage
- Synchronizable, 2.2MHz Switching Frequency
- Enable Input
- PGOOD Output
- Current-Mode Architecture
- Optional Spread Spectrum
- 2mm x 2mm x 0.85mm 8-Pin TDFN

High-Precision
- 107% OV Monitor
- 93% UV Monitor
- ±1.5% Output-Voltage Accuracy
- Forced-PWM and Skip Modes
Protection
- Overtemperature and Short-Circuit Protection
-40°C to +125°C Operating Temperature Range

Part details & applications

The MAX20071/MAX20072 high-efficiency switching regulator family delivers up to a 1A load current from 0.5V to 3.8V. The device operates from an input voltage range of 3.0V to 5.5V making it ideal for on-board point-of-load and post-regulation applications. Total output error is less than ±1.5% over load, line, and temperature.

The MAX20071/MAX20072 features fixed-frequency PWM mode operation with a switching frequency of 2.2MHz. High-frequency operation enables an all-ceramic capacitor design and small external components.

The MAX20071/MAX20072 provides an enable input and PGOOD output. The output voltage can be preset at the factory to allow customers to achieve ±1.5% output- voltage accuracy without external 0.1% resistors. In addition, the output voltage can be set to any customer value by using two external resistors at the feedback with 0.5V internal reference. The devices offers a fixed 0.85ms soft-start time.

The 8-pin TDFN exposed pad devices include overtemperature shutdown and overcurrent limiting. All devices are designed to operate from -40°C to +125°C ambient temperature.

APPLICATIONS

Automotive
Point-of-Load
