Analog Devices HMC8108 Product Info

• Conversion gain: 13 dB typical
• Image rejection: 20 dBc typical
• Noise figure: 2 dB typical
• Input power for 1 dB compression: −4 dBm typical
• Input third-order intercept: 6 dBm typical
• Output saturated power: 10 dBm typical
• LO leakage at the IF port: −20 dBm typical
• LO leakage at the RF port: −37 dBm typical
• 32-terminal, 5 mm × 5 mm, ceramic leadless chip carrier (LCC)

The HMC8108 is a compact, X-band, gallium arsenide (GaAs), monolithic microwave integrated circuit (MMIC) in-phase/quadrature (I/Q), low noise converter in a ceramic, leadless chip carrier, RoHS compliant package. The HMC8108 converts radio frequency (RF) input signals ranging from 9 GHz to 10 GHz to a typical single-ended intermediate frequency (IF) signal of 60 MHz at its output. This device provides a small signal conversion gain of 13 dB with a noise figure of 2 dB and image rejection of 20 dBc.

The HMC8108 uses a low noise amplifier followed by an image reject mixer that is driven by an active LO buffer amplifier. The image reject mixer eliminates the need for a filter following the low noise amplifier and removes thermal noise at the image frequency. I/Q mixer outputs are provided, and an external 90° hybrid is needed to select the required sideband. The HMC8108 is a much smaller alternative to hybrid style, image reject mixer, downconverter assemblies and is compatible with surface-mount manufacturing techniques.

Applications

• Point to point and point to multipoint radios
• Military radar
• Satellite communications
