HMC721LP3E

PRODUCTION

13 Gbps Fast Rise Time XOR / XNOR Gate with Programmable Output Voltage

Analog Devices HMC721LP3E Product Info

10 February 2026 6

Features

Inputs Terminated Internally in 50 Ohms
Differential or Single-Ended Operation
Fast Rise and Fall Times: 19/18 ps
Low Power Consumption: 230 mW typ.

Programmable Differential Output
Voltage Swing: 600 - 1200 mVp-p
Propagation Delay: 95 ps
Single Supply: -3.3 V
16 Lead 3×3 mm SMT Package: 9 mm²

Part details & applications

The HMC721LP3E is a XOR/XNOR gate function designed to support data transmission rates of up to 14 Gbps, and clock frequencies as high as 14 GHz.

All differential inputs to the HMC721LP3E are CML and terminated on-chip with 50 Ohms to the positive supply, GND, and may be DC or AC coupled. Outputs can be connected directly to a 50 Ohm ground-terminated system or drive devices with CML logic input. The HMC721LP3E also features an ouput level control pin, VR, which allows for loss compensation or signal level optimization. The HMC721LP3E operates from a single -3.3 V supply and is available in ROHS-compliant 3x3 mm SMT package.

APPLICATIONS

The HMC721LP3E is ideal for:

16 G Fiber Channel
RF ATE Applications
Broadband Test & Measurement
Serial Data Transmission up to 14 Gbps
Digital Logic Systems up to 14 GHz
