HMC344A

RECOMMENDED FOR NEW DESIGNS

0.1 GHz to 8 GHz, GaAs, Nonreflective, SP4T Switch

Analog Devices HMC344A Product Info

10 February 2026 7

Features

Broadband frequency range: 0.1 GHz to 8 GHz
Nonreflective 50 Ω design
Low insertion loss: 1.7 dB at 6 GHz
High isolation: 36 dB at 6 GHz
High input linearity at 250 MHz to 8 GHz
- P1dB: 28 dBm typical
- IP3: 44 dBm typical
Integrated 2 to 4 line decoder
16-lead, 3 mm × 3 mm LFCSP package
ESD HBM rating: 250 V (Class 1A)

HMC344A supports defense and aerospace applications (AQEC standard)

Download the HMC344ATCPZ-EP data sheet
Military temperature range (−55°C to +125°C)
Controlled manufacturing baseline
One assembly/test site
Product change notification
Qualification data available on request

Part details & applications

The HMC344ALP3E is a broadband, nonreflective, single-pole, four-throw (SP4T) switch manufactured using a gallium arsenide (GaAs) metal semiconductor field effect transistor (MESFET) process. This switch offers high isolation, low insertion loss, and on-chip termination of the isolated ports.

The switch operates with a negative supply voltage (V_EE) range of −5 V to −3 V and requires two negative logic control voltages.

The HMC344ALP3E includes an on-chip, binary two-line to four-line decoder that provides logic control from two logic input lines.

The HMC344ALP3E comes in a 3 mm × 3 mm, 16-lead LFCSP package and operates from a 0.1 GHz to 8 GHz frequency range.

Applications

Broadband telecommunications systems
Fiber optics
Switched filter banks
Wireless Infrastructure below 8 GHz
