DS2465

RECOMMENDED FOR NEW DESIGNS

DeepCover Secure Authenticator with SHA-256 Coprocessor and 1-Wire Master Function Advanced Physical Security Protects System Secret, Offloads Host SHA-256 Computing

Analog Devices DS2465 Product Info

10 February 2026 5

Features

SHA-256 Engine to Operate a Symmetric-Key-Based Bidirectional Secure Authentication Model
Two 32-Byte Pages of User EEPROM with Multiple Programmable Protection Options
1-Wire Master Port with Selectable Active or Passive 1-Wire Pullup
Strong 1-Wire Pullup Provided by an Internal Low-Impedance Signal Path
1-Wire Port Can Be Powered Down Under Software Control
I²C Operating (Pullup) Voltage: 3.3V ±10%
±8kV ESD Protection on IO to GND (JESD22-A114 HBM, Typical)
Operating Range: 3.3V ±10%, -40°C to +85°C
6-Pin TSOC Package

Part details & applications

DeepCover^® embedded security solutions cloak sensitive data under multiple layers of advanced physical security to provide the most secure key storage possible.

The DeepCover Secure Authenticator (DS2465) is a SHA-256 coprocessor with built-in 1-Wire^® master that provides the SHA-256 and memory functionality required by a host system to communicate with and operate a 1-Wire SHA-256 slave. In addition, it performs protocol conversion between the I²C master and any attached 1-Wire SHA-256 slaves. For 1-Wire line driving, internal user-adjustable timers relieve the system host processor from generating time-critical 1-Wire waveforms, supporting both standard and overdrive 1-Wire communication speeds. The 1-Wire line can be powered down under software control. Strong pullup features support 1-Wire power delivery to 1-Wire devices such as EEPROMs. When not in use, the DS2465 can be put in sleep mode where power consumption is minimal.

A DS2465 evaluation board is included in each of the authenticator evaluation kits below.

Applications

Authentication of Consumables
Secure Feature Control
