Analog Devices DG1209 Product Info

• Distortion-Free Measurement
  • 100Ω (typ) On Resistance
  • ≤ 1nA (max) On/Off-Leakage Current at +85°C
  • ≤ 0.5pC (typ) Charge Injection
• Wide Supply Range with Low Supply Current
  • 40µA (typ) Quiescent Current at Room Temperature
  • Fully Specified with ±15V Bipolar Supplies or +12V Single Supply
  • Rail-to-Rail Operation
• Flexible Design Option
  • GPIO-Compatible Control Inputs
  • EN Input to Enable/Disable Device
  • Available in both 16-TQFN and 16-TSSOP Packages
  • -40°C to +85°C Temperature Range

The DG1208 and DG1209 are low-leakage, low-charge injection, single 8-channel or dual 4-channel multiplexing switch devices. The DG1208 uses three selection inputs A2, A1, and A0 to determine the switching logic; the DG1209 uses two selection inputs A1 and A0. On both devices, an enable (EN) input is used to enable or disable the device.

The low capacitance and low charge injection of the DG1208/DG1209 make them ideal for automatic test equipment systems, data acquisition systems and sample-and- hold systems where low glitch and fast settling time are required.

The DG1208/DG1209 are available in 4mm x 4mm 16-lead TQFN or 16-lead TSSOP packages. The devices are specified for operation over the -40°C to +85°C temperature range.

Applications

• Automatic Test Equipment Systems
• Data Acquisition Systems
• Sample-and-Hold Systems
• Communication Systems
• Audio and Video Routing
