ADXL152

LAST TIME BUY

Low Cost, Single-Axis, PSI5-Compatible Satellite Sensor

Analog Devices ADXL152 Product Info

10 February 2026 7

Features

User configurable sensor range

±120 g, ±240 g, and ±480 g

PSI5 communication protocol, V2.1 compliant
Asynchronous operation—PSI5-A10P-250[228]/1L
Synchronous operation—PSI5-P10P-500/3L and others
- Daisy-chain operation with bidirectional communication
- Backwards compliant with PSI5 V1.3

Selectable 10- or 16-bit sensor data
High accuracy interpolation routine
User selectable, continuous auto-zero operation
Electromechanical sensor self-test
High resistance to electromagnetic interference (EMI)/ radio frequency interference (RFI)
4.5 V to 16.5 V operation
Electronic serial number
Qualified for automotive applications

Part details & applications

The ADXL152 is a g range configurable single-axis integrated satellite sensor, compliant to the PSI5 V2.1 specification. The ADXL152 enables low cost solutions for front and side impact airbag satellite sensor applications. Acceleration data is sent to the control module via a digital 2-wire current loop interface bus.

The g range of the sensor is configurable to provide full-scale acceleration measurements of ±120 g, ±240 g, or ±480 g. Additionally, the device can be configured to transmit data from multiple g ranges during predefined time slots, in accordance with the PSI5 specification. The device transmits 10- or 16-bit acceleration data to the control module, and can be configured to include either a 1-bit parity check, or a 3-bit cyclic redundancy check (CRC). The ADXL152 has a unique electronic serial number.

The ADXL152 is available in a 12-lead, 4 mm × 4 mm LFCSP package. The device is specified to operate over the full automotive temperature range, from −40°C to +125°C.

Applications

Front impact crash sensing
Side impact crash sensing
