RECOMMENDED FOR NEW DESIGNS
The ADRF5345 is a high linearity, reflective, single-pole, four-throw (SP4T) switch manufactured in the silicon process.
The ADRF5345 operates from 30 MHz to 6 GHz with a typical insertion loss lower than 0.40 dB up to 3.8 GHz, and a typical input IP3 of 84 dBm. The device has an RF input power handling capability of 39 dBm for continuous wave signals and 39 dBm average and 49 dBm peak for long-term evolution (LTE) signals.
The ADRF5345 incorporates an integrated negative voltage generator (NVG) to operate with a single positive supply of 5 V (VDD) applied to the VDD pin drawing a 2 mA supply current. The device employs low voltage complementary metal-oxide semiconductor (LVCMOS)-/low voltage transistor to transistor logic (LVTTL)- compatible controls.
The ADRF5345 comes in a 4 mm × 4 mm, 22-terminal, RoHS-compliant, land grid array (LGA) package and operates between −40°C to +105°C.
APPLICATIONS
