ADRF5032

RECOMMENDED FOR NEW DESIGNS

1 GHz to 60 GHz, Reflective, Silicon SPDT Switch

Analog Devices ADRF5032 Product Info

10 February 2026 5

Features

Ultra-wideband frequency range: 1 GHz to 60 GHz
Low insertion loss

1.3 dB typical up to 40 GHz
1.9 dB typical up to 55 GHz
2.0 dB typical up to 60 GHz

High isolation

43 dB typical up to 40 GHz
37 dB typical up to 55 GHz
32 dB typical up to 60 GHz

High input linearity

P0.1dB: 24 dBm typical
IP3: 45 dBm typical

High RF power handling

Through path: 24 dBm
Hot switching path: 21 dBm

CMOS/LVTTL compatible
No low-frequency spur
Fast RF switching time: 15 ns
RF settling time (50% V_CTRL to 0.1 dB of RF output): 35 ns
Single-supply operation capability (V_DD = 3.3 V, V_SS = 0 V)
12-terminal, 2.5 mm × 2.5 mm, RoHS-compliant, LGA package

Part details & applications

The ADRF5032 is a reflective, single-pole double-throw (SPDT) switch manufactured using the silicon process. The ADRF5032 operates from 1 GHz to 60 GHz with insertion loss of lower than 2.0 dB and isolation of higher than 32 dB. The device has an RF input power handling capability of 24 dBm for both through paths and 21 dBm for hot switching. The ADRF5032 requires dual-supply voltages of ±3.3 V. The ADRF5032 employs CMOS and low-voltage transistor to transistor logic (LVTTL)-compatible control.

The ADRF5032 can also operate with a single positive supply voltage (V_DD) applied while the negative supply voltage (V_SS) is tied to ground. In this operating condition, the small signal performance is maintained while the switching characteristics, linearity, and power handling performance are derated. See Table 2 in the data sheet for more details.

The ADRF5032 is packaged in a 12-terminal, 2.5 mm × 2.5 mm, RoHS-compliant, land grid array (LGA). The ADRF5032 operates from −40°C to +105°C.

APPLICATIONS

Industrial scanners

Test and instrumentation

Cellular infrastructure: 5G mmWave

Military radios, radars, electronic counter measures (ECMs)

Microwave radios and very small aperture terminals (VSATs)
