ADN4693E-1

RECOMMENDED FOR NEW DESIGNS

3.3 V, 200 Mbps, Full-Duplex, High Speed M-LVDS Transceiver

Analog Devices ADN4693E-1 Product Info

10 February 2026 5

Features

Full Duplex M-LVDS transceiver (driver and receiver pair)
Switching rate: 200 Mbps (100 MHz)
Type 1 receiver with hysteresis of 25 mV
Compatible with the TIA/EIA-899 standard for M-LVDS
Glitch free power-up/power-down on M-LVDS bus
Controlled transition times on driver output
Common-mode range: −1 V to +3.4 V, allowing communication with 2 V of ground noise

Driver outputs high-Z when disabled or powered off
Enhanced ESD protection on bus pins
- ≥±15 kV HBM, air discharge
- ≥±8 kV HBM, contact discharge
- ≥±10 kV IEC 61000-4-2, air discharge
- ≥±8 kV IEC 61000-4-2, contact discharge
Operating junction temperature range: −40°C to +120°C
16-lead, 4 mm x 4 mm LFCSP package

Part details & applications

The ADN4693E-1 is a multipoint, low voltage differential signaling (M-LVDS) transceiver (driver and receiver pair) that can operate at up to 200 Mbps (100 MHz) nonreturn to zero (NRZ). The receiver detects the bus state with a differential input of as little as ±50 mV over the common-mode voltage range of the device. Electrostatic discharge (ESD) protection of up to ±15 kV is implemented on the bus pins. The ADN4693E-1 is designed to the TIA/EIA-899 standard for M-LVDS and complement TIA/EIA-644 LVDS devices with additional multipoint capabilities.

The ADN4693E-1 features a Type 1 receiver with 25 mV of hysteresis so that slow-changing signals or loss of input does not lead to output oscillations.

This full-duplex device is available in a compact 16-lead, 4 mm × 4 mm lead frame chip scale package (LFCSP). The ADN4693E-1 is specified over the -40⁰C to +120⁰C junction temperature range.

APPLICATIONS

Backplane and cable multipoint data transmission
Multipoint clock distribution
Low power, high speed alternative to shorter RS-485 links
Networking and wireless base station infrastructure
Grid infrastructure and relay protection systems
