ADIS16486

RECOMMENDED FOR NEW DESIGNS

Six Degrees of Freedom Inertial Sensor

Analog Devices ADIS16486 Product Info

10 February 2026 4

Features

Triaxial digital gyroscope, ±450°/sec dynamic range (minimum)

±0.018° axis to axis misalignment error (typical)
5.3°/hr in-run bias stability (typical)
0.25°/√hr angular random walk (typical)
0.01&percnt; FS nonlinearity

Triaxial digital accelerometer, ±18 g dynamic range (minimum)
Triaxial, delta angle, and delta velocity outputs
Factory calibrated sensitivity, bias, and axial alignment

Calibration temperature range: −40°C to +85°C

SPI compatible
Single VDD power supply operation: 3.0 V to 3.6 V
2000 g mechanical shock survivability

Programmable operation and control

Automatic and manual bias correction controls
4 FIR filter banks, 120 configurable taps
Digital input and output: data ready alarm indicator, external clock
Alarms for condition monitoring
Power-down and sleep mode for power management
Optional external sync input clock: 2.4 kHz (maximum)
Continuous self test of inertial sensors
On demand self test of inertial sensors
Continuous CRC-based memory testing

Operating temperature range: −40°C to +105°C

Part details & applications

The ADIS16486 is a complete inertial system that includes a triaxis gyroscope and a triaxis accelerometer. Each inertial sensor in the ADIS16486 combines industry leading iMEMS^® technology with signal conditioning that optimizes dynamic performance. The factory calibration characterizes each sensor for sensitivity, bias, alignment, and linear acceleration (gyroscope bias). Therefore, each sensor has dynamic compensation formulas that provide accurate sensor measurements.

The ADIS16486 provides a simple, cost effective method for integrating accurate, multiaxis inertial sensing into industrial systems, especially when compared with the complexity and investment associated with discrete designs. All necessary motion testing and calibration are part of the production process at the factory, which reduces system integration time. Tight orthogonal alignment simplifies inertial frame alignment in navigation systems. The serial peripheral interface (SPI) and register structure provide a simple interface for data collection and configuration control. Parylene coating of all internal circuitry provides a protective barrier against moisture exposure.

The ADIS16486 uses the same footprint and connector system as the ADIS16480, ADIS16485, ADIS16487, and ADIS16488A, which greatly simplifies the upgrade process. The ADIS16486 is packaged in a module that is approximately 47 mm × 44 mm × 14 mm with a 24-lead standard connector interface.

APPLICATIONS

Attitude and heading reference systems
Platform stabilization and control
Unmanned vehicle navigation
Robotics and instrumentation
