RECOMMENDED FOR NEW DESIGNS
The ADH814S is a x2 active broadband frequency multiplier chip utilizing GaAs PHEMT technology. When driven by a +4 dBm drive level signal, the multiplier provides +17 dBm typical output power from 13 GHz to 24.6 GHz Fout. The ADH814S is ideal for use in LO multipliers chains for Pt-to-Pt & VSAT Radios yielding reduced parts count vs. traditional approaches. The low additive SSB Phase Noise of -136 dBc/Hz at 100 kHz offset helps maintain good system noise performance. All data taken with the chip connected via two 0.025 mm (1 mil) wire bonds of minimal length 0.31 mm (12 mils)
