Analog Devices ADGS2414D Product Info

The ADGS2414D contains eight independent, low on-resistance, single-pole/single-throw (SPST) switches in a 4 mm x 5 mm, 30 pin LGA package.

The ADGS2414D enables higher channel density in systems where printed circuit board space is constrained or existing system form factors restrict expansion.

When using SPI daisy-chain mode, the unique route through pins, provide considerable space savings when multiple ADGS2414D instances are combined to design very high channel count systems, such as large switching matrices and fanout applications. The integrated supply decoupling capacitors and SDO pullup resistor further increase the space savings and reduce printed circuit board complexity.

The low on-resistance (0.56 Ω typical) of each switch channel allows for higher current density in systems where heat dissipation is an issue, and the on-resistance profile of the switch channels is exceptionally flat over the full-analog input range, which ensures good linearity and low distortion when switching precision analog signals.

Each switch has an input signal range from V_SS to V_DD – 2 V. When on, each switch conducts equally well in both directions, and in the off condition, signal levels up to the supplies are blocked. The SPI has robust error detection features, such as cyclic redundancy check (CRC) error detection, invalid read and write address detection, and SCLK count error detection.

Applications

• Automatic test equipment
• Instrumentation
• Data acquisition
• Relay replacement
• Avionics
• Audio and video switching
• Communication systems
