ADG1236
  • ADG1236
  • ADG1236

ADG1236

PRODUCTION

Low Capacitance, Low Charge Injection, ±15 V/12 V iCMOS, Dual SPDT Switch

Analog Devices ADG1236 Product Info

10 February 2026 6

Features

  • 1.3 pF off capacitance
  • 3.5 pF on capacitance
  • 1 pC charge injection
  • 33 V supply range
  • 120 Ω on resistance
  • Fully specified at +12 V, ±15 V
  • No VL supply required
  • 3 V logic-compatible inputs
  • Rail-to-rail operation
  • 16-lead TSSOP and 12-lead LFCSP packages
  • Typical power consumption: <0.03 µW

Part details & applications

The ADG1236 is a monolithic CMOS device containing two independently selectable SPDT switches. It is designed on an iCMOS® process. iCMOS (industrial CMOS) is a modular manufacturing process combining high voltage complementary metal-oxide semiconductor (CMOS) and bipolar technologies. It enables the development of a wide range of high performance analog ICs capable of 33 V operation in a footprint that no previous generation of high voltage devices has been able to achieve. Unlike analog ICs using conventional CMOS processes, iCMOS components can tolerate high supply voltages while providing increased performance, dramatically lower power consumption, and reduced package size.

The ultralow capacitance and charge injection of the device make it an ideal solution for data acquisition and sample-and-hold applications, where low glitch and fast settling are required. Fast switching speed coupled with high signal bandwidth makes the device suitable for video signal switching. iCMOS construction ensures ultralow power dissipation, making the device ideally suited for portable and battery-powered instruments.

Each switch conducts equally well in both directions when on and has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. Both switches exhibit break-before-make switching action for use in multiplexer applications.

Product Highlights

  1. 3 pF off capacitance (±15 V supply).
  2. 1 pC charge injection.
  3. 3 V logic-compatible digital inputs: VIH = 2.0 V, VIL = 0.8 V.
  4. No VL logic power supply required.
  5. Ultralow power dissipation: <0.03 µW.
  6. 16-lead TSSOP and 12-lead 3 mm × 3 m
