The ADAR4000 is a 2 GHz to 18 GHz single-input, quad-output beamformer IC (BFIC) that is optimized for phased array transmit applications. A true, time delay-based core ensures beam-squint free wideband operation. The full-scale delay of the time delay unit (TDU) can be set to either 254 ps or 508 ps with a minimum step size of 2 ps and 4 ps, respectively. At 2 GHz, this results in a phase adjustment range of 365°, and at 18 GHz, the minimum phase step size is 13°.

Each path also has a 31.5 dB digital step attenuator (DSA) with a step size of 0.5 dB.

Control of all the on-chip registers is through a simple 3-wire or 4-wire serial port interface (SPI). Four address pins allow SPI control of up to 16 devices on the same serial lines.

The on-chip, random access memory (RAM) and first in, first out (FIFO) memory have storage for up to 64 and 16 beamstates, respectively. The on-chip sequencer can be used to select and advance the beamstate, which can be sourced from the RAM or FIFO.

The ADAR4000 is available in a 36-lead 6 mm × 6 mm LFCSP and is specified from −40°C to +85°C.

ADAR4000 is available in a 36-lead 6mm × 6mm LFCSP package and is specified from −40°C to +85°C.

APPLICATIONS

• Phased array communications links
• Satellite communications (SATCOM)
• Phased array radar
• Electronic warfare
• Test and measurement equipment
