ADAR3007

RECOMMENDED FOR NEW DESIGNS

ADAR3007 13.75GHz to 14.6 GHz 4-beam/4-element Ku band Beamformer

Analog Devices ADAR3007 Product Info

10 February 2026 6

Features

  • 13.75 GHz to 14.6 GHz frequency range
  • Low power dissipation (<12 mW per channel)
  • 4-beam/4-element beamforming IC
  • Configurable for transmit or receive operation
  • Programmable phase shifter and step attenuator for beam steering
  • Internal memory for storing beam positions
  • User programmable sequencer for quick and efficient beam state selection
    • Update, reset, & mute beam commands issued via pins or SPI
    • Supports beam hopping and raster scanning
  • Integrated ADC for:
    • Temperature sensor
    • General analog inputs
  • Programmable bias modes
  • 16 chip parallel addressability over 4-wire SPI interface
  • Easy to use BGA package

Part details & applications

ADAR3007
