ACTIVE
Number of channels |
1 |
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) |
5.5 |
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) |
2.2 |
Vos (offset voltage at 25°C) (max) (mV) |
0.05 |
Offset drift (typ) (µV/°C) |
0.1 |
Input bias current (max) (pA) |
550 |
GBW (typ) (MHz) |
0.9 |
Features |
EMI Hardened, Small Size, Zero Drift |
Slew rate (typ) (V/µs) |
0.4 |
Rail-to-rail |
In, Out |
Iq per channel (typ) (mA) |
0.125 |
Vn at 1 kHz (typ) (nV√Hz) |
20 |
CMRR (typ) (dB) |
112 |
Rating |
Catalog |
Operating temperature range (°C) |
-40 to 125 |
Iout (typ) (A) |
0.03 |
Architecture |
CMOS |
Input common mode headroom (to negative supply) (typ) (V) |
-0.05 |
Input common mode headroom (to positive supply) (typ) (V) |
0.05 |
Output swing headroom (to negative supply) (typ) (V) |
0.006 |
Output swing headroom (to positive supply) (typ) (V) |
-0.006 |
THD + N at 1 kHz (typ) (%) |
0.003 |
SOT-23 (DBV)-5-8.12 mm² 2.9 x 2.8
All trademarks are the property of their respective owners.
The OPA378 and OPA2378 represent a new generation of Zerø-Drift, microPOWER operational amplifiers that use a proprietary auto-calibration technique to provide minimal input offset voltage (20µV) and offset voltage drift (0.1µV/°C). The combination of low input voltage noise, high gain bandwidth (900kHz), and low power (150µA max) enable these devices to achieve optimum performance for low-power precision applications. In addition, the excellent PSRR performance, coupled with a wide input supply range of 2.2V to 5.5V and rail-to-rail input and output, makes it an outstanding choice for single-supply applications that run directly from batteries without regulation.
The OPA378 (single version) is available in both a microSIZE SC70-5 and a SOT23-5 package. The OPA2378 (dual version) is offered in a SOT23-8 package. All versions are specified for operation from –40°C to +125°C.
