ACTIVE
Number of channels |
1 |
Total supply voltage (+5 V = 5, ±5 V = 10) (max) (V) |
36 |
Total supply voltage (+5 V = 5, ±5 V = 10) (min) (V) |
4.5 |
Vos (offset voltage at 25°C) (max) (mV) |
0.025 |
Offset drift (typ) (µV/°C) |
0.1 |
Input bias current (max) (pA) |
20 |
GBW (typ) (MHz) |
2.5 |
Features |
EMI Hardened, High Cload Drive, e-Trim™ |
Slew rate (typ) (V/µs) |
5.5 |
Rail-to-rail |
In, Out |
Iq per channel (typ) (mA) |
0.14 |
Vn at 1 kHz (typ) (nV√Hz) |
15 |
CMRR (typ) (dB) |
140 |
Rating |
Catalog |
Operating temperature range (°C) |
-40 to 125 |
Iout (typ) (A) |
0.065 |
Architecture |
CMOS |
Input common mode headroom (to negative supply) (typ) (V) |
-0.1 |
Input common mode headroom (to positive supply) (typ) (V) |
0.1 |
Output swing headroom (to negative supply) (typ) (V) |
0.05 |
Output swing headroom (to positive supply) (typ) (V) |
-0.05 |
THD + N at 1 kHz (typ) (%) |
0.0012 |
SOIC (D)-8-29.4 mm² 4.9 x 6
The OPAx191 family (OPA191, OPA2191, and OPA4191) is a new generation of 36-V, e-trim™ operational amplifiers.
These devices offer outstanding dc precision and ac performance, including rail-to-rail input/output, low offset voltage (±5 µV, typ), low offset drift (±0.2 µV/°C, typ), and 2-MHz bandwidth.
Unique features, such as differential input-voltage range to the supply rail, high output current (±65 mA), high capacitive load drive of up to 1 nF, and high slew rate (5 V/µs), make the OPAx191 a robust, high-performance operational amplifier for high-voltage industrial applications.
The OPAx191 family of op amps is available in standard packages and is specified from –40°C to +125°C.
