• Low Supply Voltage Range: 1.8 V to 3.6 V
• Ultra-Low Power Consumption
  • Active Mode: 220 µA at 1 MHz, 2.2 V
  • Standby Mode: 0.5 µA
  • Off Mode (RAM Retention): 0.1 µA
• Five Power-Saving Modes
• Ultra-Fast Wake-Up From Standby Mode in Less Than 1 µs
• 16-Bit RISC Architecture, 62.5-ns Instruction Cycle Time
• Basic Clock Module Configurations
  • Internal Frequencies up to 16 MHz With Four Calibrated Frequencies to ±1%
  • Internal Very-Low-Power Low-Frequency Oscillator
• 16-Bit Timer_A With Two Capture/Compare Registers
• On-Chip Comparator for Analog Signal Compare Function or Slope Analog-to-Digital (A/D) Conversion (MSP430G2210 Only)
• 10-Bit 200-ksps Analog-to-Digital (A/D) Converter With Internal Reference, Sample-and-Hold, and Autoscan (MSP430G2230 Only)
• Universal Serial Interface (USI) Supports SPI and I2C (MSP430G2230 Only)
• Brownout Detector
• Serial Onboard Programming, No External Programming Voltage Needed, Programmable Code Protection by Security Fuse
• On-Chip Emulation Logic With Spy-Bi-Wire Interface
• Family Members:
  • MSP430G22x0: 2KB + 256B Flash Memory, 128B RAM
• Available in 8-Pin Plastic Packages (D)
• For Complete Module Descriptions, See the MSP430x2xx Family User's Guide (SLAU144)
