CD74HCT4066-Q1
  • CD74HCT4066-Q1
  • CD74HCT4066-Q1
  • CD74HCT4066-Q1

CD74HCT4066-Q1

ACTIVE

Automotive 9-V, 1:1 (SPST), 4-channel high-speed switch

Texas Instruments CD74HCT4066-Q1 Product Info

1 April 2026 3

Parameters

Configuration

1:1 SPST

Number of channels

4

Power supply voltage - single (V)

5

Protocols

Analog

Ron (typ) (Ω)

25

CON (typ) (pF)

5

ON-state leakage current (max) (µA)

1

Bandwidth (MHz)

200

Operating temperature range (°C)

-40 to 125

Input/output continuous current (max) (A)

0.025

Rating

Automotive

Drain supply voltage (max) (V)

5.5

Supply voltage (max) (V)

5.5

Package

SOIC (D)-14-51.9 mm² 8.65 x 6

Features

  • Qualified for automotive applications
  • Low ON resistance:
    • 25Ω typical (V CC = 4.5V)
  • Fast switching and propagation speeds
  • Low OFF leakage current
  • Wide operating temperature range: −40°C to 125°C
  • Direct LSTTL input logic compatibility: VIL = 0.8V maximum, VIH = 2V minimum
  • CMOS input compatibility: I I ≤ 1µA at VOL, VOH
  • Qualified for automotive applications
  • Low ON resistance:
    • 25Ω typical (V CC = 4.5V)
  • Fast switching and propagation speeds
  • Low OFF leakage current
  • Wide operating temperature range: −40°C to 125°C
  • Direct LSTTL input logic compatibility: VIL = 0.8V maximum, VIH = 2V minimum
  • CMOS input compatibility: I I ≤ 1µA at VOL, VOH

Description

The CD74HCT4066-Q1 contains four independent digitally controlled analog switches that use silicon-gate CMOS technology to achieve operation speeds similar to LSTTL, with the low power consumption of standard CMOS integrated circuits.

These switches feature the characteristic linear ON resistance of the metal-gate CD4066B. Each switch is turned on by a high-level voltage on its control input.
