Key Features
- Wi-Fi 6 (802.11ax)
- Bluetooth Low Energy 5.4 in CC33x1MOD
- Companion module to any processor or MCU host capable of running a TCP/IP stack
- Integrated 2.4GHz and 5GHz PA for a complete wireless system with up to +18.3dBm output power
- Operating temperature: –40°C to +85°C
- Application throughput up to 50Mbps
- Regulatory Certification
- FCC: Z64-CC33DBMOD
- IC/ISED: 451I-CC33DBMOD
- ETSI/CE
- MIC (TELEC): 201-250530 (Test Grade: 51), 201-250531 (Test Grade: 50)
- Based on CC3351 QuickTrack Qualified chipset
- Bluetooth Controller Subsystem Qualified
Extended Features
- Wi-Fi 6
- 2.4GHz and 5GHz, 20MHz, single spatial stream
- MAC, baseband, and RF transceiver with support for IEEE 802.11 a/b/g/n/ax
- Target wake time (TWT), OFDMA, MU-MIMO (downlink), Basic Service Set Coloring, and trigger-based transmission for improved efficiency
- Hardware-based encryption and decryption supporting WPA2 and WPA3
- Excellent interoperability
- Support for 4-bit SDIO or SPI host interfaces
- Bluetooth Low Energy 5.4
- LE Coded PHYs (long range), LE 2M PHY (high speed), and Advertising Extension
- Host controller interface (HCI) transport with an option for UART or shared SDIO
- Internal coexistence mechanism with Wi-Fi to share the same RF chains and antenna
- Enhanced Security
- Secured host interface
- Firmware authentication
- Anti-rollback protection
- Multirole support (for example, concurrent STA and AP) to connect with Wi-Fi devices on different RF channels (Wi-Fi networks)
- Optional antenna diversity or selection
- 3-wire or 1-wire PTA for external coexistence with additional 2.4GHz radios (for example, Thread or Zigbee)
-
Clock sources
- 40MHz XTAL fast clock (Integrated into the module)
- Internal slow clock or external 32.768kHz slow clock
- Small package size
- Easy to design with 65-pin, 11mm × 11mm LGA package, 0.65mm pitch
