Active and preferred
A/D Input Lines |
16 |
ADC (#, Max. Resolution @ Sample Rate) |
SAR (1, 12-bit @ 12 msps) |
Additional Features |
CORDIC, MOTIF Hall/Encoder, Safety Class B |
BLE Maximum Data Rate |
N/A |
BLE Power Output |
N/A |
BLE RX Sensitivity |
N/A |
BLE Supported Frequency band |
N/A |
CAN |
2 |
CapSense |
N |
Communication Interfaces |
I2C, SPI, UART |
Comparators |
5 |
CPU |
ARM Cortex-M33 |
Cryptographics Accelerator |
Y |
DAC (#, Max. Resolution @ Sample Rate) |
(5,10-bit) |
Development Software |
ModusToolbox™ |
DMA Channels |
32 |
EEPROM Emulation |
No |
Family |
PSOC™ Control C3M Main |
Flash |
128 kByte |
Floating Point Unit |
Y |
Frequency max |
180 MHz |
I/O Pins max |
50 |
I/O Pins (smart) max |
28 |
I2S |
0 |
LCD Direct Drive |
N |
Lead Ball Finish |
Pure Sn |
Number of ADC Modules |
1 |
Operating Temperature range |
-40 °C to 105 °C |
Operating Voltage range |
1.71 V to 3.6 V |
Operational Amplifier |
0 |
PDM-PCM |
0 |
Peak Reflow Temp |
260 °C |
Quad-SPI |
N |
Qualification |
Industrial |
Real Time Clock |
N |
Secondary Core |
N/A |
Serial Communication Blocks |
6 |
SRAM |
64 kByte |
Timer/Counter/PWM Blocks |
20 |
Universal Digital Blocks |
0 |
USB I/O |
0 |
