Active and preferred
Country of Assembly (Last BE site, current, subject to change) |
Malaysia |
Country of Diffusion (Last FE site, current, subject to change) |
Austria, Malaysia |
ID (@25°C) max |
50 A |
IDpuls max |
200 A |
Launch year |
2013 |
Operating Temperature range |
-55 °C to 175 °C |
Package |
DPAK (PG-TO252-5) |
Planned to be available until at least |
2030 |
Polarity |
N |
Ptot max |
47 W |
QG (typ @10V) |
25 nC |
QG (typ @10V) max |
33 nC |
Qualification |
Automotive |
RDS (on) (@10V) max |
7.2 mΩ |
RthJC max |
3.2 K/W |
Technology |
OptiMOS™T2 |
VDS max |
40 V |
VGS(th) range |
1.2 V to 2.2 V |
VGS(th) |
1.7 V |
Electric brake booster, Electronic stability control
