IMLT65R075M2H
  • IMLT65R075M2H

IMLT65R075M2H

Active and preferred

The CoolSiC™ MOSFET 650 V G2 in TOLT utilizes the CoolSiC™ Generation 2 superior switching performance, which also provides the advantages of top-side cooling. This innovation enhances the current offerings of CoolSiC™ TOLT and CoolMOS™ Q-DPAK, facilitating comprehensive system-level enhancements, including reductions in board space and BOM costs, as well as maximization of system power density.

Infineon Technologies IMLT65R075M2H Product Info

16 April 2026 0

Parameters

ID (@25°C) max

34.7 A

Mounting

SMT

Operating Temperature range

-55 °C to 175 °C

Package

TOLT

Polarity

N

Qualification

Industrial

RDS (on) (@ Tj = 25°C) max

95 mΩ

RDS (on) (@ Tj = 25°C)

75 mΩ

RthJC max

0.8 K/W

Technology

CoolSiC™ G2

VDS max

650 V

Apps

Battery energy storage (BESS), Industrial motor drives and controls, 1-phase string inverter solutions, Power conversion

Features

  • Excellent figures of merit (FOMs)
  • High robustness and overall quality
  • Flexible driving voltage range
  • Support for unipolar driving (VGS,off=0)
  • Lower thermal resistance
  • Improved package interconnect with .XT
  • Top side cooling

Description

  • Enables BOM savings
  • Maximizes the system performance per $
  • Highest reliability
  • Enables top efficiency and power density
  • Simplifies assembly and cooling
  • Water cooling "ready"
  • Allows designs without fan or heatsink
  • Lower stray inductances
  • Better gate control
