Active and preferred
Adjustable Slewrate |
Yes |
Certifications |
ISO 26262-ready |
Channel Mix RDS (on) (@ Tj = 25°C [mΩ]) |
4x22.5 |
Channel Mix RDS (on) (@ Tj = 150°C [mΩ]) |
4x38 |
Channels |
4 |
Classification |
ISO 26262-ready |
Cranking mode |
N/A |
Daisy-Chain Capability |
Yes |
External Drive Capability |
Yes |
IL(OVL0) |
48 A |
IL (@TA = 85°C with parallelization) max |
6 A |
ILNominal Current @ TA = 85°C [A] |
4x3A |
Lamp driving capability |
4x27Watt |
Limp Home Feature |
Yes |
Open Load Detection |
On and Off |
Open Load Disable Function |
N/A |
Over Current Protection |
Configurable Restart or Latch |
Overload shutdown |
Yes |
Planned to be available until at least |
2039 |
Product Category |
Smart High-Side Switches |
PWM Engine Integrated |
0 |
PWM Inputs |
2 |
Quiescent Current max |
0.4 µA |
Reverse ON |
Yes |
Short GND Detection |
Yes |
SPI |
8 Bit |
Standby Mode |
Yes |
Undervoltage Recovery Delay |
Yes |
Undervoltage Shutdown |
Yes |
Automotive body control module (BCM)
