Active and preferred
Adjustable Slewrate |
Yes |
Certifications |
ISO 26262-ready |
Channel Mix RDS (on) (@ Tj = 25°C [mΩ]) |
3x22.5 + 3x70 |
Channel Mix RDS (on) (@ Tj = 150°C [mΩ]) |
3x38 + 3x110 |
Channels |
6 |
Classification |
ISO 26262-ready |
Cranking mode |
N/A |
Daisy-Chain Capability |
Yes |
External Drive Capability |
No |
IL(OVL0) |
48 A, 18 A |
IL (@TA = 85°C with parallelization) max |
6 A |
ILNominal Current @ TA = 85°C [A] |
3x3A+3x1.5A |
Lamp driving capability |
3x27 Watt+3x10 Watt |
Limp Home Feature |
Yes |
Open Load Detection |
On and Off |
Open Load Disable Function |
N/A |
Over Current Protection |
Configurable Restart or Latch |
Overload shutdown |
Yes |
Planned to be available until at least |
2039 |
PWM Engine Integrated |
No |
PWM Inputs |
4 |
Quiescent Current max |
0.6 µA |
Reverse ON |
for 22.5mohm chls |
Short GND Detection |
Yes |
SPI |
8 Bit |
Standby Mode |
Yes |
Undervoltage Recovery Delay |
No |
Undervoltage Shutdown |
Yes |
Automotive body electronics & power distribution
