Active and preferred
Channels |
1 |
Classification |
- |
Control Interface |
Discrete |
Diagnostic Features |
Output Status |
Diagnostics |
- |
EAS/Avalanche Energy |
140 mJ |
EAS (Energy capability) |
140 mJ |
Family |
Classic HITFET™ 24V |
Features |
24V COMPATIBLE |
ID(lim) min |
10 A |
ID |
3.6 A |
IL(LIM) min |
10 A |
IL(nom) |
3.6 A |
IL (Short Circuit Current) |
10 A |
Load Current |
4.3 A |
Mounting |
SMT |
Nominal Load Current per channel |
3.6 A |
Operating Temperature range |
-40 °C to 150 °C |
Planned to be available until at least |
2039 |
Protection strategy |
Auto-restart |
RDS (on) (@ Tj = 150°C) max |
134 mΩ |
RDS (on) (@ Tj = 25°C) |
54 mΩ |
Recommended Operating Voltage max |
60 V |
toff (Turn OFF time) max |
120 µs |
ton (Turn ON time) max |
100 µs |
VDS max |
60 V |
Domain controller for ADAS & autonomous driving, Automotive body control module (BCM), Automotive battery management system (BMS) - high-voltage
