BSO613SPV G
  • BSO613SPV G

BSO613SPV G

Active

Infineon’s highly innovative OptiMOS™ families include p-channel power MOSFETs. These products consistently meet the highest quality and performance demands in key specifications for power system design such as on-state resistance and figure of merit characteristics.

Infineon Technologies BSO613SPV G Product Info

16 April 2026 0

Parameters

Budgetary Price €/1k

0.34

Ciss

700 pF

Coss

235 pF

ID (@25°C) max

-3.44 A

ID max

-3.44 A

IDpuls max

-13.8 A

Mode

Enhancement

Mounting

SMD

Operating Temperature range

-55 °C to 150 °C

Package

SO-8

Polarity

P

Ptot max

2.5 W

QG (typ @10V)

20 nC

RDS (on) (@10V) max

130 mΩ

Rth

100 K/W

VDS max

-60 V

VGS(th) range

-2.1 V to -4 V

Apps

Automotive battery management system (BMS) - 48 V, EV traction inverter, Medium voltage (MV) drive, Domestic robots

Features

  • Enhancement mode
  • Avalanche rated
  • Fast switching
  • Dv/dt rated
  • Pb-free lead-plating
RoHS compliant, Halogen-free
  • Qualified according to AEC Q101
