Analog Devices MAX5112 Product Info

• Low 3.0V Supply
• Integrated Multiplexers for Outputs 1 and 2
• Increased Current or Resolution with Outputs Connected in Parallel
• I²C-Compatible Serial Interface
• Internal Reference
• Overtemperature Protection
• -40°C to +105°C Temperature Range
• Available in 36-Bump WLP or 32-Pin TQFN Packages

The MAX5112 is a 14-bit, 9-channel, current output digital-to-analog converter (DAC). The device operates from a low +3.0V power supply and provides 14-bit performance without any adjustment.

The device's output ranges are optimized to bias a high-power tunable laser source. Each of the 9 channels provides a current source. Connect DAC outputs in parallel to obtain additional current or to achieve higher resolution. The device contains an internal reference.

An I²C-compatible interface drives the device with clock rates of up to 400kHz. An active-high asynchronous CLR input resets DAC codes to zero independent of the serial interface. The device provides a separate power-supply input for driving the interface logic.

The MAX5112 is specified over a temperature range of -40°C to +105°C and are available in 3mm x 3mm 36-bump WLP and 5mm x 5mm 32-pin TQFN packages.

Applications

• Tunable Laser Diode Biasing
