Analog Devices MAX25302A Product Info

• Delivers Flexible Operating Range
  • 1.7V to 5.5V Input Voltage Range
  • 0.6V to 5.0V Programmable Output Voltage
  • 2A Maximum Output Current
  • 100mV Maximum Dropout at 2A Load
  • < 1.5μA Shutdown Supply Current
• Reduces Noise and Improves Accuracy
  • ±1% DC Accuracy Over Load, Line, and Temperature
  • 5.1µV_RMS Output Noise, 10Hz to 100kHz
  • 1.3mA Quiescent Supply Current
  • > 70dB PSRR at 10kHz
• Enables Ease-of-Use and Robust Protection
  • Stable with 8μF (Min) Output Capacitance
  • Programmable Soft-Start Rate
  • Overcurrent and Overtemperature Protection
  • Output-to-Input Reverse-Current Protection
  • Power-OK Status Pin
• Reduces PC Board Area
  • 3mm x 3.5mm 14-pin TDFN Package
• AEC-Q100
  • -40°C to 125°C Operating Temperature

The MAX25302A/MAX25302B are 1.7V–5.5V V_IN, low-noise linear regulators that delivers up to 2A of output current with only 5.1μV_RMS of output noise from 10Hz to 100kHz. The regulator maintains ±1% output accuracy over a wide input voltage range, requiring only 100mV of input-to-output headroom at full load. The 1.3mA no-load supply current is independent of dropout voltage.

The output voltage on MAX25302B can be adjusted to a value in the range of 0.6V to 5.0V by using two external resistors. The MAX25302B also includes an active-high POK signal for trouble-free load startup.

The MAX25302A has nine pin-selectable output voltages: 1.2V, 1.5V, 1.8V, 2.5V, 3.0V, 3.1V, 3.3V, 4.0V, and 5V.

All versions include a programmable output soft-start rate, output overcurrent, and thermal-overload protection.

The MAX25302A/MAX25302B are offered in a 3mm x 3.5mm, 14-pin TDFN package.

Applications

• Automotive Electronics
• High-End Audio Systems
• High-Resolution Data-Acquisition Systems
