Analog Devices MAX14829 Product Info

• Low Power Dissipation Reduces the Thermal Footprint for Small Sensors
  • 2.3Ω/2.7Ω (typ) Driver On-Resistance
  • 60mW (typ) Operating Power Dissipation
• Configurability and Integration Reduce SKUs
  • Auxiliary 24V Digital Output (DO) and Input (DI)
  • Selectable Driver Current: 100mA to 330mA
  • Pin-Control Interface for Configuration and Monitoring
  • 3.3V and 5V Low-Noise Linear Regulators
  • Optional External Transistor Supports Higher Regulator Load Capability
  • Supervisors Monitor 24V Supply
• Selectable Driver Integrated Protection Enables Robust Communication
  • 65V Absolute Maximum Ratings on Interface and Supply Pins Allows for Flexible TVS Protection
  • 9V to 60V Specified Operation
  • Glitch Filters for Improved Burst and Noise Resilience
  • Thermal Shutdown Autoretry Cycling
  • Hot-Plug V₂₄ Supply Protection
  • Reverse Polarity Protection of All Sensor Interface Inputs/Outputs
  • -40°C to +125°C Operating Temperature Range

The MAX14829 integrates the high-voltage functions commonly found in industrial sensors. The MAX14829 features two ultra low-power drivers with active reversepolarity protection and is specified for operation with supply voltages from 9V to 60V. The high-voltage tolerance of the MAX14829 allows for the use of micro-TVS, simplifying transient protection.

Pins are used to configure and monitor the device. Driver overload and supply monitor outputs are available. Pin-control allows for operation with switching sensors that do not use a microcontroller. Two integrated linear regulators (3.3V and 5V) provide low-noise analog and logic supply rails for the device or external circuits. The MAX14829 is available in a (4mm x 4mm) 24-pin TQFN package and is specified over the extended -40°C to +125°C temperature range.

Applications

• Industrial Sensors
• IO-Link® Sensors and Actuators
• Safety Applications
