LTP8800-2

RECOMMENDED FOR NEW DESIGNS

54V, 135A DC/DC μModule Regulator with PMBus Interface

Analog Devices LTP8800-2 Product Info

10 February 2026 9

Features

High Efficiency at High Frequency
- Up to 89% Efficiency at 700kHz, 54V_IN to 0.75V_OUT
PMBus-Compliant I²C Serial Interface
- Monitor Voltage, Current, Temperature and Faults
- Internal EEPROM Fault Log Record
- Digitally Programmable Control Loop
- Program Voltage, Current Limits, Soft-Start/Soft-Stop, Frequency Synchronization and Phasing,Power-Good, Warnings, and Faults

Wide Input Voltage Range: 45V to 65V
Output Voltage Range: 0.5V to 1.0V
Optimized for 45V to 65V_IN to 0.75V_OUT
±0.5% Maximum DC Output Error with Differential Remote Voltage Sense
±3% Current Readback Accuracy
Parallel and Current Share Multiple μModule ICs
22mm × 24mm × 6.7mm Surface-Mounted Package

Part details & applications

The LTP™8800-2 is a 135A step-down μModule^® (micromodule) regulator that provides microprocessor core voltage from a 54V power distribution architecture. It features remote configurability and telemetry monitoring of power management parameters over PMBus, an open standard I²C-based digital interface protocol.

The LTP8800-2 comprises a programmable digital control system with precision mixed-signal circuitry, EEPROM, power MOSFETs, planar transformer, inductors, and supporting components. Its high level of integration minimizes component count and design time and maximizes flexibility and power density.

The LTP8800-2 preserves high efficiency at high conversion ratios by utilizing a quasi-resonant architecture that reduces high voltage switching losses.

The LTP8800-2 is available in a 22mm × 24mm × 6.7mm surface-mounted open frame package.

Applications

High Current Distributed Power Systems
Servers, Network, and Storage Equipment
Intelligent Energy Efficient Power Regulation
