ADXRS290

RECOMMENDED FOR NEW DESIGNS

Ultralow noise, dual-axis MEMS Gyroscope for Stabilization Applications

Analog Devices ADXRS290 Product Info

10 February 2026 4

Features

Pitch and roll rate gyroscope
Ultralow noise: 0.004°/s/√Hz
High vibration rejection over a wide frequency range
Power saving standby mode
80 µA current consumption in standby mode
Fast startup time from standby mode: <100 ms
Low delay of <0.5 ms for a 30 Hz input at the widest bandwidth setting

Serial peripheral interface (SPI) digital output
Programmable high-pass and low-pass filters
2000 g powered acceleration survivability
2.7 V to 5.0 V operation
−25°C to +85°C operation
4.5 mm × 5.8 mm × 1.2 mm cavity laminate package

Part details & applications

The ADXRS290 is a high performance pitch and roll (dual-axis in-plane) angular rate sensor (gyroscope) designed for use in stabilization applications.

The ADXRS290 provides an output full-scale range of ±100°/s with a sensitivity of 200 LSB/°/s. Its resonating disk sensor structure enables angular rate measurement about the axes normal to the sides of the package around an in-plane axis. Angular rate data is formatted as 16-bit twos complement and is accessible through a SPI digital interface. The ADXRS290 exhibits a low noise floor of 0.004°/s/√Hz and features programmable high-pass and low-pass filters.

The ADXRS290 is available in a 4.5 mm × 5.8 mm × 1.2 mm, 18-terminal cavity laminate package.

APPLICATIONS

Optical image stabilization
Platform stabilization
Wearable products
