ADXL359

RECOMMENDED FOR NEW DESIGNS

Low Noise, Low Drift, Low Power 3-Axis MEMS Accelerometer

Analog Devices ADXL359 Product Info

10 February 2026 4

Features

0 g offset vs. temperature (all axes): 0.45 mg/°C typical
Ultralow noise density (all axes): 80 μg/√Hz
Low power, V_SUPPLY (LDO enabled)
In measurement mode: 200 μA
In standby mode: 21 μA
Digital output features
Digital SPI and limited I²C interfaces supported
20-bit ADC
Data interpolation routine for synchronous sampling

Programmable high-pass and low-pass digital filters
Integrated temperature sensor
Voltage range options
V_SUPPLY with internal regulators: 2.25 V to 3.6 V
V_1P8ANA, V_1P8DIG with internal LDO regulator bypassed: 1.8 V typical ± 10%
Operating temperature range: −40°C to +125°C
14-terminal, 4 mm × 4 mm × 1.04 mm, LGA package

Part details & applications

The digital output ADXL3591 is a low noise density, low 0 g offset drift, low power, 3-axis microelectromechanical system (MEMS) accelerometer with selectable measurement ranges. The ADXL359 supports the ±10 g, ±20 g, and ±40 g ranges.

The ADXL359 offers industry leading noise, minimal offset drift over temperature, and long-term stability, enabling precision applications with minimal calibration.

The low drift, low noise, and low power ADXL359 enables accurate tilt measurement in an environment with high vibration, such as airborne inertial measurement units (IMUs). The low noise over higher frequencies is ideal for wireless condition monitoring.

The ADXL359 multifunction pin names may be referenced only by their relevant function for either the serial peripheral interface (SPI) or limited I²C interface.

APPLICATIONS

IMUs and altitude and heading reference systems (AHRSs)
Platform stabilization systems
Vibration sensing
Structural health monitoring
Tilt sensing
Robotics
Condition monitoring

Protected by U.S. Patents 8,472,270; 9,041,462; 8,665,627; 8,917,099; 6,892,576; 9,297,825; and 7,956,621.
