ADV7383

RECOMMENDED FOR NEW DESIGNS

Car Camera Bus Receiver with Parallel Video Output

Analog Devices ADV7383 Product Info

10 February 2026 3

Features

Car camera bus (C²B) receiver capable of receiving video data and bidirectional control data over a differential pair or single-ended cable
The ADV7383 parallel video output formats supported include:
- 8-bit and 10-bit interleaved Y/C data up to 148.5 MHz
- 2 × 8-bit separate Y/C data up to 74.25 MHz
- Embedded (start of active video (SAV)/end of active video (EAV) codes), separate horizontal sync/vertical sync/ data enable (HS/VS/DE), or image signal processor (ISP) line/frame valid type external timing signals
HD video formats supported up to 2 megapixels at 30 Hz or 1 megapixel at 60 Hz
Bidirectional control channel embedded in the C²B link for control and status data between the C²B receiver and the C²B transmitter
Enables remote configuration of the C²B transmitter
Bidirectional GPIO with either local or remote interfacing possibilities
On-chip high resolution, high speed analog-to-digital converter (ADC), buffer and anti-aliasing filter blocks for video and control channel path
Transmission of frame count data from ISP to enable the back-end electronic camera unit (ECU) or the head unit (HU) to detect stuck or skipped frames
Video test pattern generator for simplified system testing Cable equalizer capable of compensating for cable and connector insertion loss, equivalent to a 30 m twisted pair cable

On-chip echo cancellation scheme to prevent visual impact caused by impedance mismatch between cables and connectors
Protection from and diagnosis of high voltages encountered during short to battery fault condition

Part details & applications

Complete technical specifications are available for the C2 B transmitters and receivers. Contact [email protected] to complete the nondisclosure agreement (NDA) required to receive additional product information.
